Products detail
| Device Model | PP103/PPD103 | PP123/PPD123/PPHD123 | PP153/PPHD153 | unit |
| Maximum workpiece size | 1500*800 | mm | ||
| thickness range | 5~25 | mm | ||
| Number of punching die positions | 2 | Qty. | ||
| Maximum punching force | 1000 | 1200 | 1500 | kN |
| Maximum punching diameter | Φ26 | Φ30 | Φ30 | mm |
| Drilling unit | No/low-speed drilling（optional） | No/low-speed drilling/high-speed drilling（optional） | No/High speed drilling（optional） | |
| Maximum drilling diameter | None/Φ50 | None/Φ50/Φ40 | None/Φ50 | mm |
| Number of typing positions | 1 | Qty. | ||
| Typing ability | 800 | 1000 | 1200 | kN |
| Initial block size | 14*10*19/20*12*19（optional） | mm |
*The above parameters are subject to change without prior notice.
