Products detail
| Device Model | BHD500/3 | BHD705/3 | BHD1005/3 | BHD1206/3 | BHDM1206/3 | unit |
| Web width | 150-500 | 150-700 | 150-1000 | 150-1250 | 150-1250 | mm |
| Wing height | 75-350 | 75-500 | 75-500 | 75-600 | 75-600 | mm |
| Number of drilling spindles | 3 | Qty. | ||||
| Number of cutting tools per spindle | 3 | 1 | 1 | 4 | 4 | Qty. |
| Main axis small X-axis movement distance | 0-620 | mm | ||||
| Maximum drilling diameter | Φ30 | Φ30 | Φ40 | Φ40 | Φ40 | mm |
| maximum speed | 3000 | |||||
| spindle power | 7.5 | 7.5 | 15 | 15 | 15 | kW |
| Number of CNC axes | 7 | 7 | 7 | 7 | 10 | Qty. |
*The above parameters are subject to change without prior notice.
