Products detail
| Device Model | PLD2016N | PHD2016 | PHD2020S | PHD3030S | unit |
| Maximum workpiece size | 2000*1600 | 2000*1600 | 2000*2000 | 3000*3000 | mm |
| thickness range | 15~100 | mm | |||
| Workpiece clamping method | Hydraulic clamp | Hydraulic clamp+self centering chuck | |||
| Maximum drilling diameter | Φ50 | Φ60 | Φ80 | mm | |
| spindle speed | 120~560 | 0~3000 | rpm | ||
| spindle power | 5.5 | 15 | 22 | 22 | kW |
*The above parameters are subject to change without prior notice.
